JEE Main PYQs on Thermal Expansion
1.
At what temperature a gold ring of diameter 6.230 cm be heated so that it can be fitted on a wooden bangle of diameter 6.241 cm? Both the diameters have been measured at room temperature (27°C).
(Given: coefficient of linear thermal expansion of gold αL = 1.4 × 10–5 K–1)- 125.7°C
- 91.7°C
- 425.7°C
- 152.7°C
2.
Each side of a box made of metal sheet in cubic shape is 'a' at room temperature 'T', the coefficient of linear expansion of the metal sheet is ' $\alpha^{\prime}$. The metal sheet is heated uniformly, by a small temperature $\Delta T ,$ so that its new temperature is $T +\Delta T$. Calculate the increase in the volume of the metal box.- $3 a ^{3} \alpha \Delta T$
- $4 a ^{3} \alpha \Delta T$
- $4 \pi a ^{3} \alpha \Delta T$
- $\frac{4}{3} \pi a ^{3} \alpha \Delta T$
3.
A compressive force, F is applied at the two ends of a long thin steel rod. It is heated, simultaneously, such that its temperature increases by ΔT. The net change in its length is zero. Let L be the length of the rod, A is its area of cross-section. Y is Young’s modulus, and α is its coefficient of linear expansion. Then, F is equal to- (A)
- (B)
- (C)
- (D)
4.
Consider a rectangular sheet of solid material of length $ \ell = 9 $ cm and width $ d = 4 $ cm. The coefficient of linear expansion is $ \alpha = 3.1 \times 10^{-5} $ K$^{-1}$ at room temperature and one atmospheric pressure. The mass of the sheet is $ m = 0.1 $ kg and the specific heat capacity $ C_v = 900 $ J kg$^{-1}$K$^{-1}$. If the amount of heat supplied to the material is $ 8.1 \times 10^2 $ J, then the change in area of the rectangular sheet is:- \( 2.0 \times 10^{-6} \, \text{m}^2 \)
- \( 3.0 \times 10^{-7} \, \text{m}^2 \)
- \( 6.0 \times 10^{-7} \, \text{m}^2 \)
- \( 4.0 \times 10^{-7} \, \text{m}^2 \)
5.
On a temperature scale X, the boiling point of water is 65° X and the freezing point is 15° X. Assume that the X scale is linear. The equivalent temperature corresponding to 95° X on the Fahrenheit scale would be:- 63° F
- 148° F
- 48° F
- 112° F
