JEE Main 2025 April 2 Shift 1 Physics Question Paper, Exam Analysis, and Answer Keys (Available)

JEE Main Physics Questions with Solutions

Question 1:

A light wave is propagating with plane wave fronts of the type \( x + y + z = constant \). The angle made by the direction of wave propagation with the \( x \)-axis is:

• (1) \( \cos^{-1} \left( \frac{1}{\sqrt{3}} \right) \)
• (2) \( \cos^{-1} \left( \frac{\sqrt{3}}{3} \right) \)
• (3) \( \cos^{-1} \left( \frac{1}{\sqrt{2}} \right) \)
• (4) \( \cos^{-1} \left( \frac{1}{\sqrt{5}} \right) \)

The equation for real gas is given by \( \left( P + \frac{a}{V^2} \right)(V - b) = RT \), where \( P \), \( V \), \( T \), and \( R \) are the pressure, volume, temperature and gas constant, respectively. The dimension of \( ab \) is equivalent to that of:

• (1) Planck's constant
• (2) Compressibility
• (3) Strain
• (4) Energy density

A cord of negligible mass is wound around the rim of a wheel supported by spokes with negligible mass. The mass of the wheel is 10 kg and radius is 10 cm and it can freely rotate without any friction. Initially the wheel is at rest. If a steady pull of 20 N is applied on the cord, the angular velocity of the wheel, after the cord is unwound by 1 m, will be:

• (1) 20 rad/s
• (2) 30 rad/s
• (3) 10 rad/s
• (4) 0 rad/s

A slanted object AB is placed on one side of convex lens as shown in the diagram. The image is formed on the opposite side. Angle made by the image with principal axis is:

• (1) \( \frac{-\alpha}{2} \)
• (2) \( -45^\circ \)
• (3) \( +45^\circ \)
• (4) \( -\alpha \)

Consider two infinitely large plane parallel conducting plates as shown below. The plates are uniformly charged with a surface charge density \( +\sigma \) and \( -\sigma \). The force experienced by a point charge \( +q \) placed at the mid point between the plates will be:

• (1) \( \frac{3q\sigma}{4 \epsilon_0} \)
• (2) \( \frac{3q\sigma}{2 \epsilon_0} \)
• (3) \( \frac{3q\sigma}{4 \epsilon_0} \)
• (4) \( \frac{q\sigma}{2 \epsilon_0} \)

A river is flowing from west to east direction with speed of \(9\) km/hr. If a boat capable of moving at a maximum speed of \(27\) km/hr in still water, crosses the river in half a minute, while moving with maximum speed at an angle of \(150^\circ\) to direction of river flow, then the width of the river is:

• (1) 300 m
• (2) 112.5 m
• (3) 75 m
• (4) \( 112.5 \times \sqrt{3} \) m

A point charge \( +q \) is placed at the origin. A second point charge \( +9q \) is placed at \( (d, 0, 0) \) in Cartesian coordinate system. The point in between them where the electric field vanishes is:

• (1) \( \left(\frac{4d}{3}, 0, 0\right) \)
• (2) \( \left(\frac{d}{4}, 0, 0\right) \)
• (3) \( \left(\frac{3d}{4}, 0, 0\right) \)
• (4) \( \left(\frac{d}{3}, 0, 0\right) \)

The battery of a mobile phone is rated as 4.2 V, 5800 mAh. How much energy is stored in it when fully charged?

• (1) 43.8 kJ
• (2) 48.7 kJ
• (3) 87.7 kJ
• (4) 24.4 kJ

A particle is subjected to simple harmonic motions as:
\( x_1 = \sqrt{7} \sin 5t \, cm \) \hspace{1cm \( x_2 = 2 \sqrt{7} \sin \left( 5t + \frac{\pi}{3} \right) \, cm \)


where \( x \) is displacement and \( t \) is time in seconds.

The maximum acceleration of the particle is \( x \times 10^{-2} \, m/s^2 \). The value of \( x \) is:

• (1) 175
• (2) 25 \(\sqrt{7}\)
• (3) \( 5 \sqrt{7} \)
• (4) 125

The relationship between the magnetic susceptibility \( \chi \) and the magnetic permeability \( \mu \) is given by:
\( \mu_0 \) is the permeability of free space and \( \mu_r \) is relative permeability.

• (1) \( \chi = \frac{\mu}{\mu_0} - 1 \)
• (2) \( \chi = \frac{\mu + 1}{\mu_0} \)
• (3) \( \chi = \mu_r + 1 \)
• (4) \( \chi = 1 - \frac{\mu}{\mu_0} \)

A zener diode with 5V zener voltage is used to regulate an unregulated dc voltage input of 25V.
For a 400 \( \Omega \) resistor connected in series, the zener current is found to be 4 times load current.
The load current \( I_L \) and load resistance \( R_L \) are:

• (1) \( I_L = 20 \, mA; \, R_L = 250 \, \Omega \)
• (2) \( I_L = 10 \, A; \, R_L = 0.5 \, \Omega \)
• (3) \( I_L = 0.02 \, mA; \, R_L = 250 \, \Omega \)
• (4) \( I_L = 10 \, mA; \, R_L = 500 \, \Omega \)

In an adiabatic process, which of the following statements is true?

• (1) The molar heat capacity is infinite
• (2) Work done by the gas equals the increase in internal energy
• (3) The molar heat capacity is zero
• (4) The internal energy of the gas decreases as the temperature increases

A square Lamina OABC of length 10 cm is pivoted at \( O \). Forces act at Lamina as shown in figure. If Lamina remains stationary, then the magnitude of \( F \) is:

• (1) 20 N
• (2) 0 (zero)
• (3) 10 N
• (4) \( 10\sqrt{2} \) N

Let \( B_1 \) be the magnitude of magnetic field at the center of a circular coil of radius \( R \) carrying current \( I \). Let \( B_2 \) be the magnitude of magnetic field at an axial distance \( x \) from the center. For \( x : R = 3 : 4 \), \( \frac{B_2}{B_1} \) is:

• (1) 4 : 5
• (2) 16 : 25
• (3) 64 : 125
• (4) 25 : 16

Considering Bohr’s atomic model for hydrogen atom :

• (1) (B), (C) only
• (2) (A), (B) only
• (3) (A), (D) only
• (4) (A), (C) only

Moment of inertia of a rod of mass \( M \) and length \( L \) about an axis passing through its center and normal to its length is \( \alpha \). Now the rod is cut into two equal parts and these parts are joined symmetrically to form a cross shape. Moment of inertia of cross about an axis passing through its center and normal to the plane containing cross is:

• (1) \( \alpha \)
• (2) \( \frac{\alpha}{4} \)
• (3) \( \frac{\alpha}{8} \)
• (4) \( \frac{\alpha}{2} \)

A spherical surface separates two media of refractive indices \( n_1 = 1 \) and \( n_2 = 1.5 \) as shown in the figure. Distance of the image of an object \( O \), if \( C \) is the center of curvature of the spherical surface and \( R \) is the radius of curvature, is:

• (1) 0.24 m right to the spherical surface
• (2) 0.24 m left to the spherical surface
• (3) 0.24 m left to the spherical surface
• (4) 0.4 m right to the spherical surface

Match List-I with List-II.

List-I

(A) Coefficient of viscosity
(B) Intensity of wave
(C) Pressure gradient
(D) Compressibility

List-II

(I) \([ML^{-1}T^{-1}]\)
(II) \([ML^{-2}T^{-3}]\)
(III) \([ML^{-1}T^{-2}]\)
(IV) \([ML^{-1}T^{-2}]\)


• (1) (A)–(I), (B)–(IV), (C)–(III), (D)–(I)
• (2) (A)–(I), (B)–(III), (C)–(II), (D)–(I)
• (3) (A)–(IV), (B)–(II), (C)–(III), (D)–(I)
• (4) (A)–(IV), (B)–(I), (C)–(II), (D)–(III)

A small bob of mass 100 mg and charge +10 µC is connected to an insulating string of length 1 m. It is brought near to an infinitely long non-conducting sheet of charge density \( \sigma \) as shown in figure. If the string subtends an angle of 45° with the sheet at equilibrium, the charge density of sheet will be :

(1) 0.885 nC/cm\(^2\)

(2) 17.7 nC/cm\(^2\)

(3) 885 nC/cm\(^2\)

(4) 1.77 nC/cm\(^2\)

A monochromatic light is incident on a metallic plate having work function \( \phi \). An electron, emitted normally to the plate from a point A with maximum kinetic energy, enters a constant magnetic field, perpendicular to the initial velocity of the electron. The electron passes through a curve and hits back the plate at a point B. The distance between A and B is:

• (1) \( \sqrt{\frac{2m \left( \frac{hc}{\lambda} - \phi \right)}{eB}} \)
• (2) \( \frac{m \left( \frac{hc}{\lambda} - \phi \right)}{eB} \)
• (3) \( \sqrt{8m \left( \frac{hc}{\lambda} - \phi \right)} \div eB \)
• (4) \( 2 \frac{m \left( \frac{hc}{\lambda} - \phi \right)}{eB} \)

A vessel with square cross-section and height of 6 m is vertically partitioned. A small window of \( 100 \, cm^2 \) with hinged door is fitted at a depth of 3 m in the partition wall. One part of the vessel is filled completely with water and the other side is filled with the liquid having density \( 1.5 \times 10^3 \, kg/m^3 \). What force one needs to apply on the hinged door so that it does not open?

A steel wire of length 2 m and Young's modulus \( 2.0 \times 10^{11} \, N/m^2 \) is stretched by a force. If Poisson's ratio and transverse strain for the wire are \( 0.2 \) and \( 10^{-3} \) respectively, then the elastic potential energy density of the wire is \( \_\_\_ \times 10^6 \, (in SI units) \).

If the measured angular separation between the second minimum to the left of the central maximum and the third minimum to the right of the central maximum is 30° in a single slit diffraction pattern recorded using 628 nm light, then the width of the slit is ____ \(\mu\)m.

\(\gamma_A\) is the specific heat ratio of monoatomic gas A having 3 translational degrees of freedom. \(\gamma_B\) is the specific heat ratio of polyatomic gas B having 3 translational, 3 rotational degrees of freedom and 1 vibrational mode. If \[ \frac{\gamma_A}{\gamma_B} = \left( 1 + \frac{1}{n} \right) \]
then the value of \( n \) is \underline{\hspace{1cm.

A person travelling on a straight line moves with a uniform velocity \( v_1 \) for a distance \( x \) and with a uniform velocity \( v_2 \) for the next \( \frac{3x}{2} \) distance. The average velocity in this motion is \( \frac{50}{7} \, m/s \). If \( v_1 \) is 5 m/s, then \( v_2 \) is ______ m/s.
