Derive coulomb's law from gauss's law

Collegedunia Team logo

Collegedunia Team

Content Curator

According to gauss's law, the total electric flux (ϕ) through any close surface in free space is equal to 1/∈0 times the total electric charge (q) enclosed by the surface.

Derive coulombs law from gausss law que phy

Mathematically,

\(\phi = \oint _S \overrightarrow{E} . \overrightarrow{ds} = \frac{q}{ \in _0}\)

According to coulomb’s law, the magnitude of the force of attraction and repulsion between any two point charges at rest is directly proportional to the product of the magnitude of charges and inversely proportional to the square of the distance between them.

Mathematically, it is given by:

\(F=k \frac{q_1q_2}{r_2}\)

Derivation of coulomb’s law from gauss’s law

Consider two point charges q1 and q2 are separated by distance r in a vacuum.

Derivation of coulomb’s law from gauss’s law

Let E be the magnitude of the electric field at distance r from charge q1. Therefore, the force(F) experienced by charge q2 due to electric field(E) is given by:

F = q2E …(i)

Draw a gaussian surface of radius r taking the center as the location of charge q1.

The intensity of the electric field is constant at every point of this surface.

The intensity of the electric field is constant at every point of this surface.

According to gauss’s law, the net electric flux through this surface is given by

\(\oint _S \overrightarrow{E} . \overrightarrow{ds} = \frac{q_1}{ \in _0}\)

⇒ \(\oint _S\) Eds cosθ = \(\frac{q_1}{ \in _0}\)

Direction of the electric field is always perpendicular to the surface. So, the angle between E and ds is 0.

⇒ \(\oint _S\)Eds cos0 = \(\frac{q_1}{ \in _0}\)

⇒ \(\oint _S\) Eds = \(\frac{q_1}{ \in _0}\)

Since the electric field is constant at every point of the gaussian surface, therefore we can write

E \(\oint _S\) ds = \(\frac{q_1}{ \in _0}\)

But, \(\oint _S\) ds = 4πr2 is the surface area of sphere

⇒ E x 4πr2 = \(\frac{q_1}{ \in _0}\)

Using equation (i), we get

\(\frac{F}{q_2}\) x 4πr2  = \(\frac{q_1}{ \in _0}\)

⇒ F = \(\frac{1}{4 \pi \in _o} \frac{q_1q_2}{r_2}\)
