NEET 2024 Physics Question Paper with Answers and Solutions PDF S4

NEET Questions

• 1.

  सूची I को सूची II से सुमेलित कीजिए:




  नीचे दिए गए विकल्पों में से सही उत्तर का चयन कीजिए:


  • A-I, B-II, C-III, D-IV

  • A-IV, B-III, C-I, D-II

  • A-III, B-IV, C-II, D-I

  • A-III, B-II, C-I, D-IV

  View Solution

  ---

• 2.

  The figure given below shows a long straight solid wire of circular cross-section of radius ‘a’ carrying steady current I. The current I is uniformly distributed across its cross-section. The plot which correctly represents the variation of magnetic field (B) with distance (r) from the axis of the conductor in the region is: ____.




  • A
  • B
  • C
  • D
  View Solution

  ---

• 3.

  A box of mass 15 kg is kept on the floor of a stationary trolley. The coefficient of static friction between the box and the trolley is 0.12. Keeping the box in stationary state over the trolley, the maximum acceleration with which the trolley can be moved horizontally in m s⁻² is: ____.


  • 1.2

  • 1.8

  • 1.5

  • 2.1
  View Solution

  ---

• 4.

  A room heater is rated 400 W, 220 V. If the supply voltage drops to 200 V, what will be the power consumed (approximately)? ____.


  • 121 W

  • 200 W

  • 400 W

  • 331 W
  View Solution

  ---

• 5.

  When \(1\ dm^3\) of \(CO_2\) gas is passed over hot coke, the volume of gaseous mixture after complete reaction at STP becomes \(1.4\ dm^3\). The composition of the gaseous mixture at STP is:

  • \(0.6\ dm^3\) of \(CO\), \(0.8\ dm^3\) of \(CO_2\)

  • \(0.6\ dm^3\) of \(CO\), \(0.9\ dm^3\) of \(CO_2\)

  • \(0.8\ dm^3\) of \(CO\), \(0.6\ dm^3\) of \(CO_2\)

  • \(0.8\ dm^3\) of \(CO\), \(0.7\ dm^3\) of \(CO_2\)
  View Solution

  ---

• 6.

  A submarine is designed to withstand an absolute pressure of 100 atm. How deep can it go below the water surface? (Consider the density of water = 1000 kg m⁻³, 1 atm = 1 $\times$ 10⁵ Pa and g = 10 m/s²)


  • 990 m

  • 9000 m

  • 99 m

  • 9900 m
  View Solution
