Electrical Instruments is an important topic in the Physics section in VITEEE exam. Practising this topic will increase your score overall and make your conceptual grip on VITEEE exam stronger.
This article gives you a full set of VITEEE PYQs for Electrical Instruments with explanations for effective preparation. Practice of VITEEE Physics PYQs including Electrical Instruments questions regularly will improve accuracy, speed, and confidence in the VITEEE 2026 exam.
Also Read
VITEEE PYQs for Electrical Instruments with Solutions
1.
A galvanometer acting as a voltmeter will have- a high resistance in parallel with its coil
- a high resistance in series with its coil
- a low resistance in parallel with its coil
- a low resistance in series with its coil
2.
A galvanometer with a scale divided into $100$ equal divisions has a current sensitivity of $10$ divisions per milliampere and a voltage sensitivity of $2$ divisions per millivolt. The galvanometer resistance will be- $ 4 \, \Omega$
- $ 5 \, \Omega$
- $ 3 \, \Omega$
- $7 \, \Omega$
3.
An ammeter reads upto $1A$. Its internal resistance is $0.81\, \Omega$ . To increase the range to $10\, A$, the value of the required shunt is- $0.09\, \Omega$
- $0.03\, \Omega$
- $0.3\, \Omega$
- $0.9\, \Omega$
4.
In a tangent galvanometer, a current of 1A produces a deflection of 30?. The current required to produce a deflection of 60? is- 3A
- 2A
- 4A
- 1A
