OJEE 2017 M.Tech Common Engineering Mathematics Question Paper with Answer Key PDFs (May 14)

OJEE Questions

• 1.

  The parallel RLC circuit shown in the figure is in resonance. In this circuit,


  • $\lvert I_R \rvert<1 \text{ mA}$

  • $\lvert I_R + I_L \rvert>1 \text{ mA}$

  • $\lvert I_R + I_C \rvert<1 \text{ mA}$

  • $\lvert I_L + I_C \rvert>1 \text{ mA}$

  View Solution

  ---

• 2.

  Critical speed of a shaft depends upon its


  • mass

  • stiffness

  • mass and stiffness

  • stiffness and eccentricity

  View Solution

  ---

• 3.

  What is the amount of ROM needed to implement a 4-bit multiplier?


  • 1 Kbits

  • 2 Kbits

  • 4 Kbits

  • 64 bits

  View Solution

  ---

• 4.

  The time constant of the network shown in the figure is


  • $CR$

  • $2CR$

  • $CR/4$

  • $CR/2$

  View Solution

  ---

• 5.

  In the system shown below, $x(t)=\sin(t)u(t)$. In steady-state, the response $y(t)$ will be


  • $\dfrac{1}{\sqrt{2}}\sin(t-\pi/4)$

  • $\dfrac{1}{\sqrt{2}}\sin(t+\pi/4)$

  • $\dfrac{1}{\sqrt{2}}e^{-t}\sin(t)$

  • $\sin(t)-\cos(t)$

  View Solution

  ---

• 6.

  Determine $I_L$ by using Norton’s theorem.


  • $5.5 \angle 22.45^\circ$ A

  • $6.5 \angle -22.45^\circ$ A

  • $8.94 \angle -26.56^\circ$ A

  • $7.5 \angle 26.56^\circ$ A

  View Solution
