TANCET 2017 Physics Question Paper with Answer Key PDFs (March 26)

TANCET Questions

• 1.

  Choose the minimum number of op-amps required to implement the given expression. $ V_o = \left[ 1 + \frac{R_2}{R_1} \right] V_1 - \frac{R_2}{R_1} V_2 $

  • Two
  • Four
  • Three
  • One

  View Solution

  ---

• 2.

  A digital filter with impulse response $ h[n] = 2^n u[n] $ will have a transfer function with a region of convergence.

  • includes unit circle
  • excludes unit circle
  • bounded by rings with circles of radius 0.5 and 2
  • entire z-plane excluding origin and infinity

  View Solution

  ---

• 3.

  An intermediate shaft of a gearbox, supporting two spur gears A and B and mounted between two bearings C1 and C2, is shown in the below figure. The pitch circle diameters of gears A and B are 500 and 250 mm respectively. The shaft is made of alloy steel 20MnCr5. (\( S_{ut} = 620 \) and \( S_{yt} = 480 \) N/mm\(^2\)). The factors \( k_b \) and \( k_t \) of the ASME code are 2 and 1.5 respectively. The gears are keyed to the shaft. Determine the shaft diameter using the ASME code.


  • 44.52 mm
  • 59.36 mm
  • 27.15 mm
  • 38.87 mm
  View Solution

  ---

• 4.

  Bio-deterioration of hides and skin before tanning process, Hair slip occurs due to

  • Aspergillus niger

  • Streptococcus sp

  • Aspergillus fumigatus

  • Pseudomonas sp
  View Solution

  ---

• 5.

  Which of the following causal analog transfer functions is used to design causal IIR digital filter with transfer function? $$ H(z) = \frac{0.05z}{z-e^{-0.42}} + \frac{0.05z}{z-e^{-0.2}} $$ Assume impulse invariance transformation with \( T = 0.1 \, \text{s} \).

  • \( H(S) = \frac{0.5}{S+4.2} + \frac{0.5}{S+2} \)
  • \( H(S) = \frac{0.5}{S+2.1} + \frac{0.5}{S+4} \)
  • \( H(S) = \frac{0.5}{S-2.1} + \frac{0.5}{S-4} \)
  • \( H(S) = \frac{0.5}{S-4.2} + \frac{0.5}{S-2} \)

  View Solution

  ---

• 6.

  What letter replaces the question mark?




  • G

  • E

  • L

  • I
  View Solution
